Acero Aleado 24CrMo13-6

Categoría:






Acero Aleado 24CrMo13-6 – Especificaciones Técnicas y Propiedades


Acero Aleado 24CrMo13-6

Información General

El acero aleado 24CrMo13-6 es un acero de temple completo con excelente resistencia al desgaste en condición laminada. También es un excelente acero para nitruración que proporciona resistencia al desgaste mejorada. Se utiliza principalmente para varillas de perforación.

Capacidades de Producción

Ofrecemos productos terminados listos para usar con nuestras capacidades integrales de fabricación

Excelente Tenacidad

Propiedades mecánicas superiores que garantizan durabilidad

Estabilidad Dimensional

Mantiene sus dimensiones bajo condiciones de trabajo exigentes

Temple Completo

Templabilidad correspondiente a aproximadamente 130 mm

Versatilidad de Entrega

Disponible laminado, recocido blando o temple y revenido

Métodos de Producción y Formas Disponibles

Método de Producción Formas Disponibles Dimensiones Máximas
Laminado en Caliente Redondo, Plano, Placa Hasta 300mm de diámetro
Forjado en Caliente Redondo, Plano, Placa Hasta 1200mm de diámetro

Nuestras Ventajas Competitivas

Tratamiento Térmico Propio

Realizamos todos los tratamientos térmicos internamente, garantizando calidad estable y entregas rápidas

Mecanizado Integral

Ofrecemos servicios de torneado y rectificado propios, ahorrando tiempo y costos a nuestros clientes

Control de Calidad

Proceso completamente integrado que asegura consistencia y trazabilidad total

Entrega Optimizada

Productos listos para uso directo, eliminando pasos adicionales en la cadena de suministro

Composición Química

Elemento Mínimo (%) Máximo (%) Especificación
Carbono (C) 0.20 0.27 EN ISO 683-5
Silicio (Si) 0.40 EN ISO 683-5
Manganeso (Mn) 0.40 0.70 EN ISO 683-5
Cromo (Cr) 3.00 3.50 EN ISO 683-5
Molibdeno (Mo) 0.50 0.70 EN ISO 683-5
Fósforo (P) 0.025 EN ISO 683-5
Azufre (S) 0.035 EN ISO 683-5

Propiedades Mecánicas

Condición Límite Elástico (MPa) Resistencia Tracción (MPa) Alargamiento (%) Dureza
Recocido (+A) 230 HB típico
Normalizado (+N) 800 1300 típico 13 370 HB típico
Temple y Revenido (+QT) 1130 1570 típico 11 430 HB típico

Temperaturas de Transformación

Punto Temperatura (°C)
AC1 776
AC3 859

Recomendaciones de Tratamiento Térmico

Tratamiento Condición Ciclo de Temperatura Enfriamiento
Forja en Caliente +AR 840-1040°C Al aire
Normalizado +N 930-960°C Al aire
Temple y Revenido +QT 840-880°C En aceite o aire
Revenido +T 160-250°C Al aire

Propiedades Físicas Típicas

Propiedad Valor Unidad
Módulo de Young 210 GPa
Coeficiente de Poisson 0.3
Módulo de Corte 80 GPa
Densidad 7800 kg/m³
Coef. Expansión Térmica (20-300°C) 12 µm/m°K
Capacidad Calorífica (50/100°C) 460-480 J/kg°K
Conductividad Térmica 40-45 W/m°K
Resistividad Eléctrica 0.20-0.25 µΩm

Designaciones Similares

Norma BS

BS 722 M 24 – Designación equivalente según norma británica

Características de Soldabilidad

Parámetro Valor Máximo
CEV 1.21
Pcm 0.53

Aplicaciones Principales

Varillas de Perforación

Aplicación principal debido a su excelente resistencia al desgaste

Componentes Nitrurados

Ideal para tratamientos de nitruración que mejoran la resistencia superficial

Herramientas Industriales

Adecuado para herramientas que requieren alta tenacidad y dureza

Componentes de Desgaste

Excelente para piezas sometidas a condiciones de desgaste severo
