Sanicro 28

Sanicro 28 (UNS N08028, W.Nr. 1.4563, EN X1NiCrMoCu31-27-4, GB NS1104 / 00Cr27Ni31Mo3Cu), tambien conocida como Alloy 28, es un acero inoxidable austenitico de muy alta aleacion desarrollado por Sandvik en Suecia durante los anos 1960 especificamente para la produccion de acido fosforico por via humeda. Con un 27% de cromo, 31% de niquel, 3.5% de molibdeno y 1% de cobre, ofrece una resistencia excepcional en entornos con acidos mixtos, cloruros, fluoruros y sulfuro de hidrogeno, posicionandose como el material metalico mas utilizado en tubos de evaporadores de acido fosforico a nivel mundial. Suministrada por SHUNFU METAL bajo certificaciones ISO 9001 y API Q1, con aprobacion para servicio bajo ASME Calderas y Recipientes a Presion secciones I, III y VIII.

Perfil de la Aleacion Sanicro 28

El Sanicro 28 ocupa un nicho estrategico entre los aceros inoxidables superausteniticos (como el 904L) y las aleaciones base niquel (como los Hastelloy serie C). Su elevado contenido de cromo (26-28%) y molibdeno (3-4%) le confiere un PREN de 38-47, superando ampliamente al 316L (PREN 24) y al 904L (PREN 35), mientras que el 31% de niquel garantiza inmunidad practica a la corrosion bajo tension por cloruros. El cobre (0.6-1.4%) potencia la resistencia en acido sulfurico y el ultra bajo carbono (max. 0.02%) elimina la precipitacion de carburos durante la soldadura, permitiendo su uso en estado soldado. Su diseno original como material para tubos de evaporadores en plantas de acido fosforico ha sido validado por mas de 10 anos de servicio continuo en multiples instalaciones, reemplazando intercambiadores de grafito que sufrian roturas frecuentes. Industrias objetivo: produccion de acido fosforico y fertilizantes, procesamiento de acido sulfurico, petroleo y gas en pozos amargos, energia nuclear, sistemas de agua de mar y desulfuracion de gases. SHUNFU METAL produce Sanicro 28 mediante fusion AOD con control preciso de nitrogeno y analisis OES en cada colada, cumpliendo ASTM B668, B709, EN 10216-5 y los requisitos de NACE MR0175 / ISO 15156 para materiales resistentes al agrietamiento por H2S en equipos de campos petroleros.

Grados Equivalentes de Sanicro 28

Como aleacion de origen sueco con adopcion global, el Sanicro 28 esta registrado en los sistemas normativos mas exigentes, incluyendo codigos ASME para recipientes a presion. SHUNFU METAL certifica la conformidad con cada norma solicitada mediante certificado EN 10204 tipo 3.1 con trazabilidad completa.

Norma / Sistema Designacion Especificacion
ASTM / ASME UNS N08028 B668 (tubo), B709 (placa), B829 (tubo)
EN / DIN 1.4563 / X1NiCrMoCu31-27-4 EN 10088-2, EN 10216-5
ISO 4563-080-28-I ISO 9723
GB (China) NS1104 / 00Cr27Ni31Mo3Cu GB/T 15007
SS (Suecia) 2584 SS 14 25 84
AFNOR (Francia) Z1NCDU31-27-03 NFA 49-217
JIS (Japon) G 4303 / G 4305 JIS G 4303
NACE / ISO NACE MR0175 / MR0103 ISO 15156-3 (servicio amargo)
Codigo ASME Code Case 1325-18 Secciones I, III, VIII division 1
Tubo de aleacion Sanicro 28 SHUNFU METAL
Tubo Sanicro 28
SHUNFU METAL

Aplicaciones Industriales de Sanicro 28

Acido Fosforico y Fertilizantes

Tubos de evaporadores en produccion de H3PO4 via humeda (material de referencia mundial, mas de 10 anos de servicio), concentradores de acido fosforico, intercambiadores de calor en plantas de superfosfato, recuperacion de yeso con fluoruros.

Acido Sulfurico

Tuberias e intercambiadores de calor en H2SO4 40-70% desaireado y superior al 85%, rendimiento comparable a Alloy C en H2SO4 al 98%, condensadores de acido sulfurico, sistemas de dilucion y distribucion de acido.

Petroleo y Gas en Pozos Amargos

Tuberia de produccion, casing y liners en pozos profundos con gas acido (H2S/CO2), suministrado laminado en frio de alta resistencia, wirelines para instrumentacion en pozos profundos, tuberias de transporte de crudo corrosivo, intercambiadores en plantas de tratamiento de superficie.

Energia Nuclear

Intercambiadores de calor en centrales nucleares (resistencia superior a SCC, picaduras y resquicios), sistemas de tuberias criticas, componentes aprobados bajo ASME Seccion III, equipos de refrigeracion de emergencia en reactores.

Agua de Mar y Cloruros

Tuberias de agua de mar, intercambiadores refrigerados por agua marina, sistemas que soportan paradas de hasta un mes sin drenaje (T agua inferior a 30 °C), circuitos de refrigeracion industrial con cloruros, reemplazo de aleaciones de niquel y Cu-Ni que fallaron por corrosion.

FGD y Emisiones con Fluoruros

Lavadores y conductos en sistemas de desulfuracion de gases, manejo de gases de escape con fluoruros en plantas de fertilizantes, recuperacion de yeso fluorado, chimeneas y revestimientos en control de contaminacion acida, torres de absorcion de gases corrosivos.

El Sanicro 28 es el unico material que ha demostrado mas de una decada de servicio continuo como tubo de evaporador en las condiciones mas agresivas de la produccion de acido fosforico. SHUNFU METAL inspecciona cada pieza mediante UT, corrientes inducidas (ECT) y PT segun ASME Seccion V, con certificados EN 10204 tipo 3.1 y opcion de ensayos de corrosion en acido fosforico contaminado bajo el sistema API Q1.

Rango de Suministro de Sanicro 28

SHUNFU METAL suministra Sanicro 28 con enfasis en tuberia sin costura para evaporadores de acido fosforico y equipos de pozos petroleros, manteniendo inventario estrategico de los formatos de mayor rotacion. Plazos de entrega de 3 a 5 semanas en formatos comerciales y de 5 a 8 en produccion especial. Toda la produccion bajo los sistemas integrados ISO 9001 y API Q1.

Forma Proceso Rango Dimensional Norma
Tubo sin Costura Extrusion / laminacion en frio Diam. ext. 6 mm – 325 mm ASTM B668 / EN 10216-5
Placa Laminada Laminacion en caliente Esp. 3 mm – 80 mm, Ancho max. 2500 mm ASTM B709 / EN 10088-2
Chapa Laminada en Frio Laminacion en frio Esp. 0.5 mm – 6 mm, Ancho max. 2000 mm ASTM B709 / EN 10088-2
Barra Redonda Laminacion en caliente / forja Diam. 6 mm – 300 mm EN 10088-3 / EN 10272
Forja / Anillo Forja libre / laminacion de anillo Diam. 80 mm – 800 mm Segun especificacion del cliente

Composicion Quimica de Sanicro 28 (ASTM B668 / EN 10088-2)

La microestructura completamente austenitica del Sanicro 28 se estabiliza gracias a su alto contenido de niquel (30-34%), mientras que el cromo (26-28%), el molibdeno (3-4%) y el cobre (0.6-1.4%) actuan sinergicamente para proporcionar resistencia en medios oxidantes, reductores y ambientes mixtos con cloruros y fluoruros. El nitrogeno controlado (tipicamente 0.06-0.10%) eleva el limite elastico sin comprometer la ductilidad ni la soldabilidad. SHUNFU METAL produce mediante fusion AOD con control preciso del balance Cr/Ni/Mo/Cu/N y analisis OES en cada colada.

Elemento Simbolo Contenido (%)
Hierro Fe Balance (~29-40)
Niquel Ni 30.00 – 34.00
Cromo Cr 26.00 – 28.00
Molibdeno Mo 3.00 – 4.00
Cobre Cu 0.60 – 1.40
Manganeso Mn Max. 2.00
Silicio Si Max. 0.70
Nitrogeno N Max. 0.10 (tipico 0.06-0.10)
Carbono C Max. 0.020
Fosforo P Max. 0.020
Azufre S Max. 0.010

El PREN del Sanicro 28 se situa en 38-47 (PREN = %Cr + 3.3x%Mo + 16x%N), muy superior al 904L (PREN ~35) y al 316L (PREN ~24). La clave de su exito en acido fosforico radica en la combinacion de alta resistencia a la corrosion por picaduras y resquicios (gracias al Cr y Mo) con la tolerancia al acido sulfurico (gracias al Cu) y la inmunidad a la corrosion bajo tension por cloruros (gracias al alto Ni), todo ello en una matriz de hierro que mantiene el coste bajo control. SHUNFU METAL controla el PREN calculado de cada colada como parametro de calidad interno, con valores objetivo superiores a 40, documentado en el certificado quimico bajo el sistema ISO 9001.

Propiedades Mecanicas de Sanicro 28 (Recocido por Solucion)

Tratamiento termico: recocido por solucion a 1040-1100 °C con enfriamiento rapido en agua o aire forzado. Este ciclo disuelve todas las fases secundarias en la matriz austenitica y alivia las tensiones residuales de la conformacion. Para aplicaciones en pozos petroleros (tuberia de produccion y casing), el Sanicro 28 se suministra en condicion laminada en frio de alta resistencia, alcanzando hasta el doble del limite elastico de la condicion recocida. El laboratorio de SHUNFU METAL, acreditado bajo API Q1, certifica las propiedades de cada lote mediante ensayos ASTM E8 y dureza ASTM E18.

Propiedad Valor Unidad Norma
Resistencia a la Traccion (Rm) 500 – 700 MPa ASTM B668 / EN 10088-2
Limite Elastico (Rp0.2) 220 (min.) MPa ASTM B668 / EN 10088-2
Alargamiento (A5) 35 (min.) % ASTM B668 / EN 10088-2
Dureza Max. 240 HBW HBW ASTM B668
Modulo de Elasticidad (20 °C) 200 GPa Calculado
Densidad 8.00 g/cm³ Calculado
Punto de Fusion 1350 – 1410 °C Rango

Para aplicaciones downhole en pozos petroleros, SHUNFU METAL suministra Sanicro 28 laminado en frio de alta resistencia con limites elasticos superiores a 690 MPa, cumpliendo NACE MR0175 / ISO 15156-3. La aleacion registra solo 0.03 mm/ano de corrosion en acido superfosforico al 95% contaminado a 200 °C, frente a 0.23 mm/ano del UNS N08020, consolidandose como el material de referencia para evaporadores de acido fosforico. SHUNFU METAL entrega los protocolos completos con cada despacho bajo el sistema API Q1.
